How to Choose a Hydraulic Shearing Machine? Jiuying's Guide

There are many different models of hydraulic swing Shearing machine. So, how to choose the most suitable for our company? First of all, we must determine the specifications and parameters of the purchased machines according to the demand parameters. At the same time, we must also consider the needs of the future expansion of the enterprise scale to leave a certain margin to determine the parameters of the machine. For CNC shears, the required range of the material thickness of the sheared material, the size of the slitting machine, etc., after the machine model parameters are determined, you can contact the manufacturer for purchase.

How to choose a suitable Shearing machine

There are many types of shears, which can be divided into:

1. Flat blade Shearing machine:

The shearing quality is good, the distortion is small, but the shearing force is large, and the energy consumption is large. More mechanical transmission. The upper and lower blades of the shearing machine are parallel to each other, and are often used for hot shearing of blooms and slabs in rolling mills; according to the shearing method, it can be divided into up-cutting and down-cutting.

2. Special Shearing machine:

It can be used with other equipment to fulfill special purpose

Plate opening and leveling line shearing machine: used on the plate uncoiling and leveling line, a high-speed shearing machine designed to meet the high-speed cutting requirements of the production line. The thick plate line is mostly hydraulic high-speed shearing machine, and the thin plate line is equipped with pneumatic Shearing machine; high-speed line equipped with flying shears, continuous production, high efficiency.

3. Multi-purpose Shearing machine:

1. Combined punching and shearing machine: it can complete the cutting of the plate and the profile, which is mostly used in the blanking process

2. Sheet bending and shearing machine: that is, two processes of shearing and bending can be completed on the same machine.

4. Oblique blade Shearing machine:

The upper and lower blades of the shearing machine form an angle. Generally, the blades are inclined, and the inclination angle is generally 1°~6°. The shearing force of the oblique-blade shearing machine is smaller than that of the flat-blade shearing machine, so the motor power and the weight of the whole machine are greatly reduced, and the actual application is the most. Shearing machine manufacturers produce this type of shearing machine. This type of shears is divided into gate shears and pendulum shears according to the movement form of the knife holder; according to the main transmission system, it is divided into hydraulic transmission and mechanical transmission.

Cold bending forming line shearing machine: for example, special shearing machine configured on production lines such as automobile longitudinal beam cold bending line, car side baffle production line, color steel plate forming line, etc.

Shearing machine for steel structure production line: It is mostly used for angle steel and H-beam automatic production line to complete the cutting process.

According to the thickness of the plate, the commonly used shears include: mechanical shears, hydraulic swing shears, hydraulic guillotine shears, and all shears are electrically driven.

If you look at the price, you can choose either the electronic digital display or the full CNC directly. Don't buy semi-CNC products that are too low-end or irrelevant. This can reduce labor costs to a limited extent and increase production efficiency.
