Automatic rotary gun welding machine of electric water heater production line
Automatic rotary gun welding machine of electric water heater production line
Automatic welding machine for welding joint surface turn gun, PLC automatic control equipment, USES the artifact does not turn, welding torch rotation mode, adjusting mechanism can be adjusted to omni-directional welding torch, meet the requirements of welding technology and welding speed can be achieved by dc motor stepless adjustment, welding torch into the given, ascend, and reset the automatic control, stable and reliable running, the clamping adopts positioning, convenient for work-piece loading and unloading.
The welding machine adopts CO2 welding method, the welding gun rotates, the workpiece is fixed, and the welding position is horizontal.There is a disc bracket and a positioning hole shaft to support the welding gun end in the middle.The operation of the whole machine is controlled by PLC, the rotation of the workpiece is controlled by PLC ac frequency conversion control.
Automatic rotary gun welding machine of electric water heater production line Main technical parameters
| 型号 Mode1 | ZQH-300 | ZQH-1000 | ZQH-500 |
| 输出功率 Input power | 220V50HZ | 380V50HZ | 220V50HZ |
| 额定功率 Rated power | 14 | 14 | 14 |
| 压力范围 Pressurerange(Map) | 0.1-0.6 | 0.1-0.6 | 0.1-0.6 |
| 工作直径 Work piece diameter | 100-300 | 100-1000 | 50-500 |
| 工作长度 Work piece length | 30-1000 | 30-1000 | 20-500 |
